Kami adalah importir distributor agen dan supplier Aquafine UV terlengkap untuk menyediakan berbagai kebutuhan spare part water treatment untuk keperluan industri dengan price harga terbaik

Maximum Flow Rate

·         Disinfections (@94% UVT) GPM (m3/hr) : 130 (30)

·         Disinfections (@99% UVT) GPM (m3/hr) : 156 (36)

Number of Lamp ( Single – Ended ) : 12

Electrical Requirements

·         Electrical Supply : 120 or 240V/50-60Hz, Single Phase, 2 W + GN D

·         Opperating Power Watts : 540

·         Ballast Type : Electronic

Controller / Detector

·         UV & Temperature Monit. System : Optional

·         Lamp Status Indicator : Standard

·         Lamp Uut Alert (LOA) : Optional

·         Running Time Meter : Standard

·         Hand Off Auto (HOA) : Optional

Control Cabinet

·         Control cabinet system rating : NEMA 1

·         Materials Of Construction : 304 Stainless Steel

Overall Dimensions

·         Inches : 44 x 11 x 28

·         MM : 1118 x 280 x 712

Treatment Chamber

Materials of Construction 316L Stainless Steel

Internal Surface Finish : Ra 32 (Ra 15 optional)

Operating Temperature °F (°C)

·         Water : 50° - 100° (10° - 38°)

·         Ambient Air : 50° - 110° (10° - 43°)

Max . Operating Pressure PSI (Bar ) : 120 (8) (150 (10) Optional )

Inlet /Outlet flange Size :  inches (mm ) 3 (80)
